SMARTFY 600W Dimmer Switch | Aluminum D8B LED & Incandescent Wall Dimmer

SMARTFY 600W Dimmer Switch | Aluminum D8B LED & Incandescent Wall Dimmer

The SMARTFY 600W Dimmer Switch provides precise dimming for LED and incandescent lights.
Energy-efficient design reduces standby power while maintaining smooth control.
Premium aluminum panel ensures durability and a modern appearance.
Flush-mounted installation fits standard 86mm wall boxes for clean integration.
Supports residential, office, and hotel lighting systems.
Compatible with multiple lighting types including dimmable LEDs and incandescent lamps.
Modular design allows 1–5 gang configurations for flexible wall layouts.

Category:

SMARTFY 600W Dimmer Switch

Aluminum D8B Series | High-Voltage Wall-Mounted Dimmer

Product Introduction

The SMARTFY 600W Dimmer Switch is designed to provide smooth and precise lighting control for LED, incandescent, and compatible AC lamps. Engineered for residential, commercial, and hospitality environments, it delivers energy-efficient dimming with minimal flicker. The premium aluminum panel with metal surface craftsmanship ensures durability and a modern aesthetic while integrating seamlessly into SMARTFY D8B modular wall systems.

General Product Information

  • Brand: SMARTFY

  • Product Name: 600W Dimmer Switch

  • Switch Type: High-Voltage Dimmer

  • Series: D8B Aluminum Series

  • Category: AC Lighting Control / Dimmer

  • Applications: Homes, offices, hotels, commercial spaces

  • Ideal For: LED lights, incandescent lamps, and compatible dimmable lighting

Electrical & Performance Specifications

  • Operating Temperature & Humidity: -10℃ to +45℃, ≤95% RH (Non-condensing)

  • Storage Temperature & Humidity: -25℃ to +70℃, ≤95% RH (Non-condensing)

  • Maximum Supply Voltage: 90–264VAC, 50/60Hz

  • Rated Operating Voltage: 100–242V AC

  • Input Frequency Variation Range: 47–50/60–63Hz

  • Maximum Output Power Load:

    • LED: 100W

    • Incandescent Lamp: 300W

  • Standby Power: 1W

  • Neutral Line / Live Line: Required

  • High-Voltage Compatibility: Yes

Installation & Mechanical Design

  • Installation Method: Flush-mounted in-wall installation

  • Wall Box Compatibility: Standard 86mm wall box

  • Embedded Depth: ≥45mm

  • Mounting Style: Screw-fixed installation

  • Installation Orientation: Horizontal or vertical

  • Conjoined Options: 1-Gang / 2-Gang / 3-Gang / 4-Gang / 5-Gang

  • System Compatibility: Fully compatible with SMARTFY D8B modular frames

Materials & Surface Finish

  • Front Panel Material: High-grade Aluminum

  • Internal Components: High-quality dimmer circuitry for smooth load control

  • Surface Treatment: Spray-coated / Brushed finish

  • Surface Properties: Scratch-resistant, corrosion-resistant, easy to clean

  • Color Options: Multiple premium finishes available

Dimensions & Configuration

  • Product Dimensions: W: 86 mm × H: 86 mm × D: 9.9 mm (excluding base)

  • Panel Design: Slim, modern profile for flush wall integration

  • Modular Fit: Compatible with other D8B series sockets and switches

Key Product Features (Brief)

  • Smooth dimming control for LED and incandescent lights

  • High-voltage compatible with 90–264V AC supply

  • Minimal standby power consumption (1W)

  • Premium aluminum panel with metal surface craftsmanship

  • Flush-mounted design for modern interiors

  • Long operational lifespan with reliable dimmer circuitry

  • Modular design supports 1–5 gang configurations

  • Ideal for homes, offices, hotels, and commercial lighting
