SMARTFY 13A BS Socket with Switch | Aluminum D8B Series High-Voltage Wall Socket

SMARTFY 13A BS Socket with Switch

Aluminum DBB Series | High-Voltage Power Socket

---

Product Introduction

The SMARTFY 13A BS Socket with Switch is a high-performance electrical accessory designed for modern architectural spaces where safety, durability, and aesthetics are critical. Manufactured with a precision-engineered aluminum front panel and high-quality internal components, this socket ensures stable power delivery under high-voltage conditions. Its minimalist design seamlessly integrates into luxury interiors while meeting the functional demands of residential, hospitality, and commercial installations.

---

General Product Information

• Brand: SMARTFY

• Product Name: 13A BS Socket with Switch

• Product Type: Wall-mounted power socket

• Socket Standard: British Standard (BS)

• Series: D8B Aluminum Series

• Category: High-Voltage Electrical Accessories

• Recommended Applications: Smart homes, hotels, serviced apartments, offices, retail outlets, and commercial buildings

---

Electrical & Performance Specifications

• Rated Current: 13 Amperes

• Rated Voltage: 250V AC

• Frequency: 50/60Hz

• Switch Mechanism: Double Pole

• High-Voltage Compatibility: Yes

• Relay Function: Not included

• USB Charging Function: Not supported

• Power Stability: Designed for continuous high-load operation

---

Wiring & Electrical Safety

• Wiring Method: Live line / Neutral line

• Double Pole Isolation: Disconnects both live and neutral lines for maximum protection

• Electrical Protection: Engineered to reduce arcing and overheating

• User Safety: Complies with international electrical safety standards

• Indicator / Backlight: Not available

---

Installation & Mechanical Design

• Installation Method: In-wall, flush-mounted installation

• Wall Box Compatibility: Standard 86mm wall box

• Recommended Embedded Depth: ≥45mm

• Mounting Method: Screw-fixed mounting system

• Installation Orientation: Horizontal or vertical

• Mechanical Lifespan: ≥100,000 switching cycles

---

Materials & Surface Finish

• Front Panel Material: High-grade aluminum alloy

• Internal Structure: Flame-retardant engineering plastic

• Surface Treatment: Brushed or spray-coated finish

• Surface Properties: Scratch-resistant, corrosion-resistant, easy to clean

• Available Colors: Multiple premium color options

---

Dimensions & Modular Configuration

• Module Size: 52 × 65 mm

• Frame Size: 86 × 86 mm (excluding mounting base)

• Panel Thickness: Optimized for seamless wall integration

• Conjoined Configurations: Single-gang to 5-gang modular layouts

• System Compatibility: Fully compatible with SMARTFY modular switch systems

---

Detailed Wall Box & Internal Space Design

• Wall Box Type: Standard 86mm electrical wall box

• Minimum Box Depth: ≥45mm

• Box Material Compatibility: Plastic and metal wall boxes

• Internal Layout: Optimized terminals for easy and secure wiring

• Heat Management: Designed for thermal stability during long-term use

• Cable Clearance: Adequate space to minimize wire stress and bending

---

Key Product Features

Designed to deliver safety, durability, and refined aesthetics, the SMARTFY 13A BS Socket with Switch combines premium materials with reliable electrical engineering to meet the demands of high-end residential and commercial environments.

• Premium aluminum panel with architectural-grade finish

• British Standard 13A socket for universal plug compatibility

• Double pole switching for enhanced electrical safety

• High-voltage rated for heavy-duty appliance use

• Long operational lifespan with durable internal components

• Modular design supporting multi-gang installations

• Ideal for luxury interiors and high-traffic applications
